BRP 177202 13.875 X 11 Aluminium Three Blade Right Hand Rotation Prop Hydrus (177202)

The Bombardier Recreational Products 13.875 X 9 A3R PROP HYDRUS is a propeller (BRP). It is an aluminum-based substance that becomes harder and more durable as it ages. It’s a three-bladed propeller that rotates on the right side. The pitch angles are fine-tuning to accelerate and channel water, reducing slides and improving performance and efficiency. It is a little heavier, weighing around 8.00 pounds. For navigational purposes, this weight is a good size. This tilt gives improvement to the machine’s overall performance and boat lift. The prop Hydrus is 13.875 inches in diameter and has a pitch distance of 9 inches each revolution.

Key features:

• Vents had been refining for a very quick hole-shot.
• Through severe rake, it improves handling and boat lift.
• Blade design with a high rake for faster speeds.
• Mid-range outboards have improved performance.
• A big blade in a larger area is necessary for significant reverse thrust.
• In any water condition, the unique blade profile provides maximum thrust.
• Proven to achieve unrivaled results “at work” and elsewhere
• Superior materials provide unrivaled safety and comfort.

Product Details:

• SKU: 177202
• UPC: 824375016783
• Weight: 8.00 LBS
• MATERIAL: Aluminum
• PITCH: 11

Pontoons, high reverse thrust

Engine Application

2-Stroke 40-60 Horsepower Two Cylinder Large Gearcase, 55-75 Horsepower Three Cylinder 75-140 Horsepower Four Cylinder

40/50/60 hp (Evinrude® E-TEC™)…2004-thru, 45 hp (Commercial)…1986-thru;
50 hp… 1971-74;
50 hp (Commercial)…1980-thru;
55 hp (Commercial)…1980-thru;
55 hp…1968-69;
60 hp…1970-71;
60 hp…1986-96;
65 hp…1972-73;
65 hp (Commercial)…1984-2001;
70 hp…1974-2001;
75 hp (large gearcase)…1975-84;
75 hp…2004-thru;
85 hp…1969-80;
85 hp…1991-95;
88 hp…1981-thru;
90 hp…2004-thru;
90 hp…1981-thru;
100 hp…1979-80;
100 hp…1988-thru;
100 hp…2004-thru;
110 hp…1986-89;
115 hp…1973-thru;
120 hp1986-94;
125 hp…1971-72;
135 hp…1973-76;
140 hp…1977-84;
140 hp…1986-94

Attaching Hardware:H25

60-70 Horsepower 4-Stroke Continued

70 hp (Evinrude® & Johnson® 4 Cyl.)…1998;
70 hp (Evinrude 4 Cyl.)…1999-2001;
60-70 hp (Johnson 4 Cyl.)…2002-thru

Attaching Hardware:H23

Attaching Hardware

H25

Cotter pin:
Sierra: 18-3742
Cotter pin (100/box):
Other: 354622
Nut:
Sierra: 18-3705
Quicksilver: 859929
Spacer, nut, & pin kit:
Sierra: 18-3716
Quicksilver: 802010Q1
Splined spacer (aft):
Sierra: 18-4228
Quicksilver: 859892
Thrust washer (forward):
Sierra: 18-4222
Quicksilver: 859915

H23

Cotter pin:
Sierra: 18-3735
Flat washer:
Other: 5030441
Nut:
Sierra: 18-3726
Splined spacer washer (aft):
Sierra: 18-3798
Other: 5030925
Splined spacer, washer, nut & cotter pin kit:
Sierra: 18-3774
Thrust washer (forward) 60 hp ’02-’03, 70 hp ’01-’03:
Other: 5032551
Thrust washer (forward) 70 hp 1998, 2000 TNT (20″ shaft):
Other: 5030924

H76

Cotter pin:
Sierra: 18-3742
Cotter pin (100/box):
Other: 354622
Nut:
Sierra: 18-3705
Quicksilver: 859929
Spacer, nut, & pin kit:
Sierra: 18-3716
Quicksilver: 802010Q1
Splined spacer (aft):
Sierra: 18-4228
Quicksilver: 859892
Thrust washer (forward):
Sierra: 18-4222
Quicksilver: 859915
Michigan Wheel: 991210

This product replaces:

824375016783, 175294, BRP177202, BRP175294, 177202
