Description
Galaxy Style 5223-XT
8 ft. (2.43 M) CB Marine
Continuous-load, end-fed-wave
A tuneable, easily installed CB antenna for top performance in demanding situations. Connector is supplied but not installed, so only a 3/8in hole is required for passage of the cable. Coax length can be altered on this antenna.
Stainless Steel ferrule with standard 1-inch 14-thread
Includes 20ft RG-8/X cable, which can be cut to size, and a PL-259 connector
Suggested mount: Shakespeare Style 4187 Ratchet Mount, or use a 410 Mounting Kit and a 5228 Extension Mast (each sold separately) to form a 16′ antenna system
Frequency: 27 MHz Citizens Band
One section
Twin to: Shakespeare Style 5225-XT
Suggested mount(s): 4187 409-R
Galaxy 5223-XT Specifications
Band: CB Marine
Max. Input Power: 25 watts
SWR: 1.5:1 or less at Channel 19
Bandwidth: 440 kHz within 2.0:1 VSWR
Ferrule: Stainless steel
Coax Supplied: 20 ft of RG-8/X
Connector Supplied: PL-259, not attached
Color/finish: Galaxy White
DC Ground: DC Grounded – The antenna will read shorted on continuity test.
